RainDance Water Systems Commercial Chlorine Chemical Water Filtration

Restaurants, Breweries, Distilleries, & Commercial Carbon Treatment Systems

Click Here To See Pricing and Equipment Information
Commercial Carbon Filter Guide: Single 3/4" | Single 1" / 1.25" | Single 1.5" | Single 2" | Twin Series


RDWS-CARB Light Commercial & Commercial Water Systems
No Chemicals! No Routine Replacement Maintenance!

The most common reason for installing our RDWS-CARB Series is to improve the taste and odor of water. Activated carbon filters from RainDance Water Systems can filter chlorine, chemicals, and chemical odors to improve water quality for your craft beer making, distillery, and restaurant drinking water. Our coconut shell activated carbon yields what many believe a sweeter taste. Our customers have enjoyed excellent water quality from our virtually maintenance free "sweet water" coconut shell carbon filtration systems.

Note: Chloramine is now used as a disinfectant by many municipal water providers and it is harder to remove by using standard carbon filtration. Most RainDance Carbon Filters can now be customized to filter chloramines upon request. Chloramine is a much more concentrated process compared to the filtration for chlorine. Chloramine needs specific contact time and slower flow rates through a specialized filter media specifically created to take care of Chloramine. Contact us today to find out what solutions we offer for enhanced chloramine filtration.


Carbon FilterIron Max Catalog

RainDance Water Systems Commercial Carbon Filters

The RDWS-CARB series is effective at filtering chlorine, chemical odors, and organic compounds at high flow rates!

Automatic Backwashing - No routine filters to buy or replace! *Carbon media should be replaced approx. every 3-5 years.

Customizable - Design your filter to treat chlorine, chloramine, or both! *Prices subject to change. Contact us!

Free Shipping - Specified filters ship free within the continental US!

Great Warranty - Lifetime warranty on media tank; carbon filtration performance guarantee!

NSF Certified Components & Filtration Media!

Specified Carbon Filters are delivered preloaded with media, saving time, money, and headache!

Coconut shell-based activated carbon media - NSF/ANSI Standard 61 - AWWA B604-96 - EN12915 - Halal & Kosher Certified!

Our RDWS-CARB Series can accommodate much higher flow rates than listed. Generally, the lower the flow rate, the more time the contaminant will have to diffuse into a pore and be adsorbed. Adsorption by activated carbon is almost always improved by a longer contact time. Thus, we've decided to list the recommended flow rate for optimum filtration and removal.

Typical Applications: Craft Beer, Distillery, Beverage Production - Restaurant Drinking Water - Protection of ion exchange resins from chlorine and organic fouling

Granular Coconut Shell Based Activated Carbon Media Certifications and Approvals - NSF / ANSI Standard 61 - AWWA B604-96 - EN12915 - Halal certified - Kosher certified

CERTIFIED DRINKING WATER TREATMENT MEDIA

WQA/ASPE/ANSI S-802: (2014) Sustainable Activated Carbon Media for Drinking Water Treatment is within WQA's ANSI approved scope of accreditation under the Sustainability Certification Scheme

From California to Texas to New York to Hong Kong Brew Masters Have Been Successfully Using RainDance Water Systems

Scroll Down for Prices or Request Information

RainDance Water Systems Carbon Filter Quote

Name:
Company Name:
Email Address:
Describe Your Application:


RDWS-CARB Catalog


Limited Time RainDance Water Systems Carbon Filter Special:

Have peace of mind and ensure your new RDWS-CARB does the job with On-The-Spot Chlorine Water Testing! While supplies last we're including this chlorine test kit with every RDWS-CARB system so you can test your water before and after your new commercial carbon filter and see the results for yourself. Easy to Use - Immediate Results​​​ - Includes 50 Testing Strips *Offer will end without notice.


Carbon FilterMilitary Discounts

RainDance Water Systems 3/4" RDWS-CARB Chlorine Filters
Small Batch / Light Commercial Carbon Filtration Series


Our best-selling 3/4" Plumbing Ports light commercial business carbon filter. This system includes: 3/4" MNPT Plumbing Ports with Bypass, Digital Timer Valve - Ships preloaded with media for easy installation! Power: Standard 110v 60hz - Chlorine test kit now included with every RDWS-CARB Series!

Model # Tank Size Pipe Size Service
Flow Rate
Est. Peak
Flow Rate
Est. Gallon
Per Day Use
Price
RDWS-CARB-9 9"D
61"H
3/4" 3gpm 10gpm 1-300 GPD $895.00
*Free Shipping




Carbon FilterMilitary Discounts

RainDance Water Systems 1" or 1.25" RDWS-CARB Chlorine Filters
Light Commercial Carbon Filtration Series


Light commercial 1" or 1.25" carbon filters - These systems includes: 1" OR 1.25" MNPT Plumbing Ports with Bypass (*Please specify port size when ordering), Digital Timer Valve - Power: Standard 110v 60hz - Chlorine test kit now included with every RDWS-CARB Series. *RDWS-CARB-125-10 & 125-12 systems are shipped preloaded with media for easy installation!
Model # Tank Size Pipe Size Service
Flow Rate
Est. Peak
Flow Rate
Est. Gallon
Per Day Use
Price
RDWS-CARB-125-10 10"D
65"H
1" OR 1.25" 5gpm 16gpm 1-600 GPD $995.00
*Free Shipping

RDWS-CARB-125-12 12"D
65"H
1" OR 1.25" 6gpm 18gpm 1-900 GPD $1,095.00
*Free Shipping

*RDWS-CARB-125-14 14"D
75"H
1" OR 1.25" 10gpm 30gpm 1-1,200 GPD $1,295.00
*Free Shipping

*RDWS-CARB-125-16 16"D
75"H
1" OR 1.25" 14gpm 35gpm 1-1,500 GPD $1,395.00
*Free Shipping

*Due to weight and ease of maneuverability the RDWS-CARB-125-14 & 16 will have tank and media shipped separately on pallet. Each filter system includes simple easy to follow step by step filling instructions.



Carbon FilterMilitary Discounts

RainDance Water Systems 1.5" RDWS-CARB Chlorine Filters
Super Duty High Flow Commercial Carbon Filtration Series


High flow c
ommercial 1.5" carbon filters - These systems includes: 1.5" MNPT Plumbing Ports, Digital Timer Valve - Power: Standard 110v 60hz - Chlorine test kit now included with every RDWS-CARB Series!

2 or more RDWS-CARB systems can be plumbed in parallel to accommodate larger flow rate capacities!
Model # Tank Size Pipe Size Service
Flow Rate
Est. Peak
Flow Rate
Price
RDWS-CARB-2814 14"D x 75"H 1.5" 10gpm 30gpm $1,695.00
*Free Shipping

RDWS-CARB-2816 16"D x 75"H 1.5" 14gpm 35gpm $1,795.00
*Free Shipping

RDWS-CARB-2818 18"D x 75"H 1.5" 18gpm 40gpm $2,195.00
*Free Shipping

RDWS-CARB-2821 21"D x 75"H 1.5" 24gpm 45gpm $2,395.00
*Free Shipping

*Due to weight and ease of maneuverability these systems will have tank and media shipped separately on pallet. Each filter system includes simple easy to follow step by step filling instructions.

Carbon Filter
RainDance Water Systems 2" RDWS-CARB Chlorine Filters
Heavy Duty High Flow Commercial Carbon Filtration Series


High flow c
ommercial / industrial 2" carbon filters - These systems includes: 2" MNPT Plumbing Ports, Digital Timer Valve - Power: Standard 110v 60hz - Chlorine test kit now included with every RDWS-CARB Series!

2 or more RDWS-CARB systems can be plumbed in parallel to accommodate larger flow rate capacities!
Model # Tank Size Pipe Size Service
Flow Rate
Est. Peak
Flow Rate
Price
RDWS-CARB-3124 24"D x 85"H 2" 28gpm 70gpm Get A Quote >>>
*Shipping Quoted Upon Request
RDWS-CARB-3130 30"D x 88"H 2" 45gpm 75gpm Get A Quote >>>
*Shipping Quoted Upon Request
RDWS-CARB-3136 36"D x 90"H 2" 64gpm 80gpm Get A Quote >>>
*Shipping Quoted Upon Request

*Due to weight and ease of maneuverability these systems will have tank and media shipped separately on pallet. Each filter system includes simple easy to follow step by step filling instructions.

Carbon FilterMilitary Discounts

RainDance Water Systems 1" Twin RDWS-CARB Filters
Dual Tank Continuous Chlorine Filtration Systems


Do you have a high demand for filtered water? The Twin Alternating RDWS-CARB tanks provide an uninterrupted supply of filtered water to your commercial business. The Twin RDWS-CARB has two tanks for filtering chlorine, chemical tastes & odors, and organic chemicals. Water is filtered in one tank while the other is in a standby mode. When the filtering capacity of the first tank is reached, the system automatically switches tanks. The first tank then starts the backwashing cycle. This cycle is repeated when the second tank reaches its capacity point.

Light commercial
1" twin alternating carbon filters - These systems includes: 1" MNPT Plumbing Ports, Digital Timer Valve - Ships preloaded with media for easy installation! Power: Standard 110v 60hz - Chlorine test kit now included with every RDWS-CARB Series!
Model # Tank Size Pipe Size Service
Flow Rate
Est. Peak
Flow Rate
Price
TWIN-RDWS-CARB-10 (2) Tanks:
10"D x 65"H
1" 5gpm 16gpm $1,795.00
*Free Shipping

TWIN-RDWS-CARB-12 (2) Tanks:
12"D x 65"H
1" 6gpm 18gpm $1,895.00
*Free Shipping

Larger TWIN-RDWS-CARB Systems Available Upon Request - Contact Us For A Quote

Iron Max Iron Filter

VIQUA IHS22-D4 12gpm Integrated UV Disinfection & Filtration System
Treats Bacteria, Lead, Chlorine, Sediment, Cloudy Water & Turbidity

Iron Max Iron Filter
IHS22-D4 Complete Integrated UV Price: $1,149.00
*Online Special Sale Price!




Model # IHS22-D4 12gpm VIQUA UV System
Operating Conditions Flow Rate: 12gpm @ 30mJ/cm2 Dose
Ambient Temperature: 36F-104F
Pressure Range: 5-125 psi
Dimensions Inlet/Outlet: 3/4" NPT
Overall Dimensions: 25.5" x 12" x 28"
Weight: 35lbs
Power 110v 60hz 50W
Prefilters (1) 20" 5 micron Sediment, Debris, Turbidity Prefiltration
(1) 20" Carbon Taste, Odor, & Lead Removal Prefiltration
Parameters 99.99% destruction of bacteria, viruses, and protozoan cysts
Total iron is less than 0.3ppmm
Hydrogen Sulfide is less than 0.05ppmm
Suspended Solids is less than 10ppmm
Manganese is less than 0.05ppmm
Water Hardness below 7 gpg

Viqua IHS22-D4 Integrated UV features:
  • High Flow 12gpm Space Saving Design!
  • Perfect integrated UV water purification for light commercial breweries, whole house, drinking water systems, well water, city water, livestock, and more.
  • System comes supplied with sediment filter and carbon block to filter lead, insecticides, herbicides, pesticides, chlorine, color, chemical tastes, cloudy water and sediment particles commonly found in water. Reduces the need for expensive pre-treatment systems!
  • The special lamp plug ensures that no one can power the UV lamp if it's not in the UV chamber.
  • Lamps and sleeves are assembled together for ease of handling. They can be replaced separately, in minutes and without tools.
  • The reference card outlines the most important system functions and maintenance for quick, on-the-spot questions.
  • Our high output validated UV lamp is engineered to treat variable water conditions.
  • The system comes equipped with high flow filters allowing the water pressure to remain consistent.
  • Bracket is a gauge steel that is powder coated for both durability and aesthetics.
  • NEW LCD controller features a large backlit display for easy reading, simultaneously displaying lamp life remaining, support contact information, and lamp replacement reminder that indicates when the lamp needs to be replaced, ensuring continued water safety. The intuitive, user friendly menu is dealer programmable and allows the user to quickly find the replacement parts needed for the system by using the replacement parts menu, as well as on board quick-reference instructions for system troubleshooting.
  • We're here when you need us! Unmatched customer and tech support with multiple channels of communication at all hours of the day and night - 365 days a year!
.


VIQUA IHS22-E4 22gpm Integrated UV Disinfection & Filtration System
Treats Bacteria, Lead, Chlorine, Sediment, Cloudy Water & Turbidity

Iron Max Iron Filter
IHS22-E4 Complete Integrated UV Price: $1,495.00
*Online Special Sale Price!




Model # IHS22-E4 22gpm VIQUA UV System
Operating Conditions Flow Rate: 22gpm @ 30mJ/cm2 Dose
Ambient Temperature: 36F-104F
Pressure Range: 5-125 psi
Dimensions Inlet/Outlet: 1" NPT
Overall Dimensions: 25" x 12" x 36.6"
Weight: 38lbs
Power 110v 60hz 83W
Prefilters (1) 20" 5 micron Sediment, Debris, Turbidity Prefiltration
(1) 20" Carbon Taste, Odor, & Lead Removal Prefiltration
Parameters 99.99% destruction of bacteria, viruses, and protozoan cysts
Total iron is less than 0.3ppmm
Hydrogen Sulfide is less than 0.05ppmm
Suspended Solids is less than 10ppmm
Manganese is less than 0.05ppmm
Water Hardness below 7 gpg

Viqua IHS22-E4 Integrated UV features:
  • High Flow 22gpm Space Saving Design!
  • Perfect integrated UV water purification for large home, craft beer breweries, food & beverage business, drinking water systems, well water, city water, livestock, restaurants, and more.
  • System comes supplied with sediment filter and carbon block to filter lead, insecticides, herbicides, pesticides, chlorine, color, chemical tastes, cloudy water and sediment particles commonly found in water. Reduces the need for expensive pre-treatment systems!
  • The special lamp plug ensures that no one can power the UV lamp if it's not in the UV chamber.
  • Lamps and sleeves are assembled together for ease of handling. They can be replaced separately, in minutes and without tools.
  • The reference card outlines the most important system functions and maintenance for quick, on-the-spot questions.
  • Our high output validated UV lamp is engineered to treat variable water conditions.
  • The system comes equipped with high flow filters allowing the water pressure to remain consistent.
  • Bracket is a gauge steel that is powder coated for both durability and aesthetics.
  • NEW LCD controller features a large backlit display for easy reading, simultaneously displaying lamp life remaining, support contact information, and lamp replacement reminder that indicates when the lamp needs to be replaced, ensuring continued water safety. The intuitive, user friendly menu is dealer programmable and allows the user to quickly find the replacement parts needed for the system by using the replacement parts menu, as well as on board quick-reference instructions for system troubleshooting.
  • We're here when you need us! Unmatched customer and tech support with multiple channels of communication at all hours of the day and night - 365 days a year!
